CNC Woodworking Sliding Table Saw , Knife Cutting Machine For Leather Cutting

Minimum Order Quantity : Negotiable Price : Negotiable
Packaging Details : Seaworthy wooden case Delivery Time : 15-30days
Payment Terms : T/T, L/C Supply Ability : 200 sets/year
Place of Origin: Qingdao, China Brand Name: OSETMAC
Certification: CE Model Number: RC1625

Detail Information

Weight: 1200KG Model: RC1625
Warranty: 12 Months Voltage: 380V/50Hz/3Ph

Product Description



Features:

High speed: Only need 80 seconds to finish one set of car foot mat., only need 6 minutes to finish one set of car cushion mattress



High efficiency: don't need any die mold, or die mold cutting machine, this machine can press mark, cutting and molding on soft material such as leather, carton etc. Save much labor and cost.



Low cost: one machine can do design, cutting instead of manual design and cutting, save labor, and material wastage cost.



Wide application: This machine can cut leather, PU, fiber, EVA, XPE, sponge cladding, composite cladding,



Sponge+drape+composite leather, PVC foot mat, paper, carton, plastic board etc. Soft material.



Good performance: adopt Taiwan TBI ball screw or Wuxi High precision rack pinion, low noise, accurate transmission. Long lifespan and high precision.



CNC Woodworking Sliding Table Saw , Knife Cutting Machine For Leather Cutting

Cnc oscillating knife cutting machine Application:



Sofa, seat, car seat cover, automobile floor mat, automotive carpet, luggage, handbags industries, applied to the shoe industry, clothing industry, composite materials, luggage industry, automobile industry, advertising printing industry, electronics industry, decoration industry, furniture industry and so on.





Description & Specifications:
Model RC-1625
X working size 1600mm
Y working size 2500mm
Z working size 50mm, max cutting thickness of material is 50mm
Cutting head cnc oscillating knife cutting head + Pneumatic pen + V shape cutting head + Red dot position
Display way English LED touch screen
Machine table Suction Table+auto loading and unloading table
Compatible format PLT,DXF,HPG,PPD,ARR,DST,DSB,EPS,DAT
Software ET
Control system Zhongrui
Data transfer way Intel
Vacuum pump 9KW air type vacuum pump
Driving system Taiwan Delta servo driver and motor
Whole power 12kw
Control system RD control system
Guiding system Taiwan TBI square rail
Tool sensor With, red dot
Transmission Y rack pinion, XZ synchronous steel belt
Cutting speed 30m/min
Traveling speed 50m/min
Weight About 1200kgs
Size 2250*3300*1650mm
Power 380V+10%,50HZ+10%
Applicable materials suitable for textile, sponge, foam, corrugated board, paper, plastic film and other soft material



Different outlook for your choice

CNC Woodworking Sliding Table Saw , Knife Cutting Machine For Leather Cutting

CNC Woodworking Sliding Table Saw , Knife Cutting Machine For Leather Cutting



CNC Woodworking Sliding Table Saw , Knife Cutting Machine For Leather Cutting
