High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY

Place of Origin CHINA
Brand Name OSET
Certification ISO CE
Model Number MJ6116TY
Minimum Order Quantity Negotiable
Price Negotiable
Packaging Details wooden case
Delivery Time 5-15workdays
Payment Terms L/C, T/T, Western Union
Supply Ability 5000sets per year

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
After-sales Service Provided Engineers Available To Service Machinery Overseas,video Technical Support, Online Support,field Maintenance And Repair Service Voltage 380v,220v/380v/415v/440v Or As Customer Request
Style Horizontal Usage Woodworking, Wood Cutting, Table Saw , Wood Working, Cut Wood
Sliding Table Dimension(l*w*h) 1600*375mm Power(w) 5.5+1.1kw/4+0.75kw
High Light

sliding panel saw machine

,

sliding table circular saw machine

Leave a Message
Product Description

High Precision woodworking sliding table saw MJ6116TY cuting wood machine for making furniture



Quick Detail:

Inner Structure

This machine uses linear guideway to lift the saw blade which is more smooth and more

durable. Aluminum shell motor makes sure its good heat dissipation. 25mm metal plate

guarantees the compressive strength and the high precision of the inter-machine, which

can also reduce the shock of the machine

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 0

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 1

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 2

2.Main Saw and Scorning Saw Spindle

After the heating processing and dynamic balancing treatment, our saw spindle will never deformation. With high quality belt and motor, our machine has lower noise, higher precision and higher efficiency of power transmission.

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 3

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 4

3.SKF Bearing

All bearings in this machine are all imported SKF brand, which has lower sliding resistance and power consumption comparing with ordinary bearings.

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 5

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 6

4.​Sliding Table Structure and Feature

Our table is made of fully-extruded, anodized aluminum that will stay square and true over many years of use. The guideway of movable table is steel bar structure. After quenching and chromizing, our table is more smooth and less resistance. The comb lock on the table makes it convenient to stop anywhere. The length of table is from 1300-4200mm according to your requirements.

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 7High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 8

5.Cast-iron Main Table and Extension Table

(sliding panel saw )

After precision casting and flat grinder treatment, our cast-iron table greatly reduces the friction between the workpiece and the table, which makes sure of the cutting accuracy.

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 9

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 10

6.Supporting Arm and Cross Cut Table

Our support arm uses 2.5mm square steel tube, which insure the stationary movement of sliding table when the machine has heavy loading. It also has angle ruler in the cross cut table.

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 11

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 12

7.controlling board

The controlling board is easy to operate. The rotation of hand wheel for saw blade tilting is very light and handy. And digital readout is available if you need.

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 13

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 14

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 15

8.Orange Dust Hood and Riving Knife

The orange dust hood is fixed on the riving knife, which is very easy to adjust. It also has the fuctions of warning, protection and dust absorption.

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 16

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 17

9.Rip Fence Fine Adjustment

Fine adjustment range is between 0-10mm, which makes the saw cutting size more precise. It is also very easily to adjust.

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 18

10.Hand Swage





High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 19

11.saw blade guard

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 20

                                                                         Optional Device

1. Altendour-structure Dust Cover

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 21

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 22

2. Digital Readout

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 23

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 24

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 25

3.Oil Injector

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 26



Note: The price in the price list does not including these optional devices.



More Trading Details

Model MJ6116TY
Payment Terms T/T
Delivery Time Negotiable (7-30DAYS)
FOB Port Qingdao Port, China
Country of Origin China
HS CODE 8465910000
Certificate CE



Our Certificate :

We have CE and ISO certificate ,Think All our models can meet the quality level in your market .

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 27



Different outlook for different customer

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 28

Our Warehouse

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 29

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 30

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 31

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 32

High Precision Woodwork Sliding Table Saw Furniture Making Machine MJ6116TY 33

Applications:

This machine apply to processing all kinds of density boards, shaving boards, wood-based panels, ABS panels, PVC panels, organic glass plates and solid wood and others with wood structure and similar hardness.



Main Technical Parameter :



Sliding Table Dimension 1600*375mm
Main saw Diameter 300mm
Main saw blade Diameter Maximum 315mm
Main saw spindle Diameter  30mm
Height of cut with saw blade at 90° 80mm(φ300)
Height of cut with saw blade at 45° 50mm(φ300)
Main Motor Power 4.0kw(5.5kw)
Speed of Main saw blade spindle   4000/6000RPM
Scoring saw blade diameter 120mm
Scoring saw spindle diameter 20mm
Main Blade Speed 4000/6000RPM
Scoring Saw Blade Diameter 120mm
Scoring Saw Bore Diameter 20mm
Scoring Motor  0.75KW(1.1KW)
Speed of Scoring spindle /scoring saw blade 8000r/min
Width of cut between saw blade and rip fence  1250mm
Gross cut capacity  3100mm
Blade Tilting Adjustment/Tilting saw blade  0-45°
Main Saw Height Adjustment Manual
Scoring Saw Height Adjustment Manual

Dust Guard Outlet Diameter

80mm

Dust System Outlet Diameter 100mm
Overall Dimensions  1600*2450*900mm
Gross Weight 550kg



Packing and Loading container
