SYS-320 Automatic Woodworking Edge Banding Machine For Particle Board
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Voltage | 220V/380V | After-sales Service Provided | Field Maintenance And Repair Service |
|---|---|---|---|
| Type | Edge Banding Machine | Panel Thickness | 10-60mm |
| Name | Edge Trimming Saw Machine | Feeding Speed | 12-24m/min |
| High Light | woodworking edge bander,edge banding trimming machine |
||
Product Description
SYS-320 Automatic Edge Banding Machine with full functions for particle board, plywood and PVC
Features
1. Through special structure, the edge-sealing sheet and the edge-sealing material are evenly coated and pressed, so that the edge-sealing strip is more firmly attached.
2. Through the precision linear guide motion, the rapid cutting structure of the high-frequency high-speed motor is automatically tracked by the master to ensure that the cut surface is smooth and smooth.
3. using the model automatic tracking and high-frequency high-speed motor structure, repair the excess edge banding material on the edge of the board edge strip.
4, used to eliminate the ripples caused by the cutting process of trimming non-linear motion.
5. Clean the finished plate with a cotton polishing wheel and smooth the edge of the edge by polishing.
Applications:
This edge banding machine is suitable for PVC, ABS, MDF, Solid, shaving board, Melamine, Batten, Veneer ,plywood and particle board etc.
Specifications:
| MODEL | SYS-320 |
| Panel Thickness | 10-60mm |
| Edge Band Thickness | 0.4-3mm |
| Panel Width | ≥60mm |
| Panel Length | ≥150mm |
| Feeding Speed | 15m/min |
| Working Pressure | 0.6Mpa |
| Voltage | 380V/50HZ/3PH |
| Gluing Motor | 0.37KW 50HZ 1400RPM |
| End Cutting Motor | 0.37KW * 2 200HZ 12000RPM |
| Fine Trimming Motor | 0.75KW * 2 300HZ 18000RPM |
| Buffing Motor | 0.37KW * 2 50HZ 1400RPM |
| Conveyor Motor | 1.5KW |
| Glue Pot Heating Power | 1.5KW |
| Assistant Heating Power | 0.3KW |
| Lighting Power | 0.05KW |
| Total Power | 6.7KW |
| Dimension | 3120x670x1270mm |
| Net Weight | 700KGS |
Competitive Advantage:
- This new model edge banding machine is small-sized with automatic function, which can load 10 sets in one 20’ GP container and 20 sets in one 40’ GP container.
- We can customize the outlook and functions of the machine according to your requirement.
- We have two wholly-owned manufacturing factories and can make sure of the delivery time.
