Customized Voltage Industrial Table Saw Machine for Woodworking at Manufacturing Plant
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xCondition | New | Type | Panel Saw |
---|---|---|---|
Use | Woodworking, Wood Cutting | Style | VERTICAL |
Voltage | Customized | Dimension(L*W*H) | 3250*3450*900mm |
Warranty | 1 Year | Application | Furniture Factory, Wood Board Factory |
Weight (KG) | 800 KG | Power (kW) | 5.5KW |
Key Selling Points | High-accuracy | Max.Cutting Height At 90°(mm) | 100mm |
Max.Cutting Height At 45°(mm) | 70mm | Max. Length Of Workpiece (mm) | 3200mm |
Applicable Industries | Machinery Repair Shops, Manufacturing Plant, Woodworking | Marketing Type | New Product 2023 |
Machinery Test Report | Provided | Video Outgoing-inspection | Provided |
Warranty Of Core Components | 1 Year | Core Components | Motor |
Support Table Dimension | 910*620*80mm | Extension Table | 905*680*70mm |
Cutting Extension Table | 640*680*70mm | Main Saw Blade Diameter | 300mm |
Main Saw Blade Diameter Maximum | 350mm | Main Saw Bore Diameter | 30mm |
Scorning Saw Blade Diameter | 120mm | Scorning Saw Bore Diameter | 20mm |
Scorning Saw Motor Power | 1.1KW | Blade Tilting Adjustment | 0-45° |
Industrial Table Saw Machine for Woodworking Premium Wood Saw Tool
* This machine uses linear guideway to lift the saw blade.
* All bearings in this machine are all imported SKF brand.
* The table is made of fully-extruded, anodized aluminum.
* With cast-iron main table and broaden extension table.
* The main saw blade lifting is electric control.
* The hand wheel for saw blade tilting is very light.
* Fine adjustment range is between 0-10mm.
* Digital Readout is available according to your requirement.
* There are comb lock on the table.
Parameters | |||
Sliding Table Dimension | 3200*390mm | ||
Cast Iron Table Dimension | 910*620*80mm | ||
length extension table | 905*680*70mm | ||
width cutting extension table | 640*680*70mm | ||
Main Saw Diameter | 300mm | ||
Main Saw Blade Diameter Maximum | 350mm | ||
Main Saw Bore Diameter | 30mm | ||
Max. Cutting Height With Bade at 90 | 80/100mm(φ300/350) | ||
Max. Cutting Height With Bade at 45 | 50/70mm(φ300/350) | ||
Main Motor Power | 5.5KW | ||
Main Blade Speed | 4000/6000RPM | ||
Scorning Saw Blade Diameter | 120mm | ||
Scorning Saw Bore Diameter | 20mm | ||
Scorning Saw Motor Power | 1.1KW | ||
Scorning Blade Speed | 8000RPM | ||
Max. Cutting Width | 1250mm | ||
Max. Cutting Length | 3100mm | ||
Blade Tilting Adjustment | 0-45° | ||
Main Saw Height Adjustment | Electric | ||
Scorning Saw Height Adjustment | Manual | ||
Dust Guard Outlet Diameter | 80mm | ||
Dust System Outlet Diameter | 100mm | ||
Dimension of Wood Packing Carton | 2250*1200*1100mm(Main Crate ) | ||
3400*450*290mm(Sliding Table) | |||
Dimension | 3250*3450*900mm | ||
G. W. | 800KG |
