Product Details:
|
| Voltage: | 220V/380V | After-sales Service Provided: | Field Maintenance And Repair Service |
|---|---|---|---|
| Type: | Edge Banding Machine | Panel Thickness: | 10-60mm |
| Name: | Edge Trimming Saw Machine | Feeding Speed: | 12-24m/min |
| High Light: | 24m/Min Automatic Edge Banding Machine,MDF Board Automatic Edge Banding Machine,Shaving Board Automatic Edge Banding Machine |
||
12-24m/Min Automatic Edge Banding Machine MDF Shaving Board
Applications of Automatic Edge Banding Machine:
This edge banding machine is suitable for PVC, ABS, MDF, Solid, shaving board, Melamine, Batten, Veneer ,plywood and particle board etc.
Specifications of Automatic Edge Banding Machine :
| MODEL | SYS-320 |
| Panel Thickness | 10-60mm |
| Edge Band Thickness | 0.4-3mm |
| Panel Width | ≥60mm |
| Panel Length | ≥150mm |
| Feeding Speed | 15m/min |
| Working Pressure | 0.6Mpa |
| Voltage | 380V/50HZ/3PH |
| Gluing Motor | 0.37KW 50HZ 1400RPM |
| End Cutting Motor | 0.37KW * 2 200HZ 12000RPM |
| Fine Trimming Motor | 0.75KW * 2 300HZ 18000RPM |
| Buffing Motor | 0.37KW * 2 50HZ 1400RPM |
| Conveyor Motor | 1.5KW |
| Glue Pot Heating Power | 1.5KW |
| Assistant Heating Power | 0.3KW |
| Lighting Power | 0.05KW |
| Total Power | 6.7KW |
| Dimension | 3120x670x1270mm |
| Net Weight | 700KGS |
Competitive Advantage:
