6 Function Automatic Edge Band Machine SYS-360 Speed Panel Feed Speed m/min 25m/min

  • 6 Function Automatic Edge Band Machine SYS-360 Speed Panel Feed Speed m/min 25m/min
  • 6 Function Automatic Edge Band Machine SYS-360 Speed Panel Feed Speed m/min 25m/min
  • 6 Function Automatic Edge Band Machine SYS-360 Speed Panel Feed Speed m/min 25m/min
  • 6 Function Automatic Edge Band Machine SYS-360 Speed Panel Feed Speed m/min 25m/min
  • 6 Function Automatic Edge Band Machine SYS-360 Speed Panel Feed Speed m/min 25m/min
  • 6 Function Automatic Edge Band Machine SYS-360 Speed Panel Feed Speed m/min 25m/min
Place of Origin Shandong, China
Brand Name OSETMAC
Price $8,600.00/sets 1-3 sets

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Condition New Type Edge Banding Machine
Voltage 380v, 380v 50HZ 3 Ph Dimension(L*W*H) 4100x800x1560mm
Power (kW) 7.4KW Weight (KG) 1200 Kg
Applicable Industries Building Material Shops, Manufacturing Plant, Construction Works  Warranty 1 Year
Function Gluing, Fine Trimming, End Trimming, Scraping, Buffing Key Selling Points Long Service Life
Panel Feed Speed(m/min) 25m/min Video Outgoing-inspection Provided
Warranty Of Core Components 1 Year Core Components Motor
Use Furniture Production Panel Thickness 10-60mm
Panel Width ≥60mm Panel Length ≥150mm
Workign Pressure 0.6Mpa Edge Thickness 0.3-3mm
HS Code 8465100000 Gluing Pot Heating Power 1.5KW
Conveyor Motor 1.5kw After-sales Service Provided Video Technical Support
Leave a Message
Product Description
Product Description
Automatic Edge Banding Machine SYS-360
6 Function Automatic Edge Band Machine SYS-360 Speed Panel Feed Speed m/min 25m/min 0
6 Function Automatic Edge Band Machine SYS-360 Speed Panel Feed Speed m/min 25m/min 1
6 Function Automatic Edge Band Machine SYS-360 Speed Panel Feed Speed m/min 25m/min 2
6 Function Automatic Edge Band Machine SYS-360 Speed Panel Feed Speed m/min 25m/min 3
Main Technical Parameter
SPECIFICATIONS
Model
SYS-360
Panel Thickness
10-60mm
Edge Band Thickness
0.3-3mm
Panel Width
≥60mm
Panel Length
≥150mm
Feeding Speed
15m/min
Working Pressure
0.6Mpa
Voltage
380V/50HZ/3PH
Gluing Motor
0.37KW/50HZ/1400RPM
End Cutting Motor
0.37KW * 2/200HZ/12000RPM
Rough Trimming Motor
0.55KW * 2/200HZ/12000RPM
Fine Trimming Motor
0.55KW * 2/200HZ/12000RPM
Buffing Motor
0.37KW * 2/50HZ/1400RPM
Conveyor Motor
1.5KW
Glue Pot Heating Power
1.5KW
Assistant Heating Power
0.3KW
Lighting Power
0.05KW
Total Power
7.4KW
Dimension
4100x800x1560mm
Wooden Case Package
3900x870x1700mm
Our Advantages
6 Function Automatic Edge Band Machine SYS-360 Speed Panel Feed Speed m/min 25m/min 4
Features of SYS-360
Descriptions * 6 Functions: Gluing--End Cutting--Rough Trimming--Fine Trimming--Scraping--Buffing * Working Voltage: 380V/50HZ /3PH * PLC Touch Screen * CC highspeed motor. *Honeywell travel switch, contactor, air switch. *Air Tac solenoid valve, air cylinder,oil-water seperator. *14mm high strenth steel sheet for the whole machine. * In the machine is mounted lights. * Support customization for the machine appearance.
Packing&Shipping
6 Function Automatic Edge Band Machine SYS-360 Speed Panel Feed Speed m/min 25m/min 5
6 Function Automatic Edge Band Machine SYS-360 Speed Panel Feed Speed m/min 25m/min 6
6 Function Automatic Edge Band Machine SYS-360 Speed Panel Feed Speed m/min 25m/min 7
6 Function Automatic Edge Band Machine SYS-360 Speed Panel Feed Speed m/min 25m/min 8
After Sales Service
6 Function Automatic Edge Band Machine SYS-360 Speed Panel Feed Speed m/min 25m/min 9
Our Service
The whole machine is guaranteed for one year, providing installation and use video, lifelong technical support and parts service
Company Introduction
OSETMAC focuses on woodworking machines for over 8 years. OSETMAC has two wholly-owned manufacturing factory--Qingdao Three OneThree Machinery Company. Our factory have been well-recognized as a professional
woodworking machine producers. The main products of OSETMAC is sliding table saw, brush sanding machine, edge banding machine,
wood drilling machine and CNC routers. What’s more, our products have been sold to more than 30 countries and regions in Middle East, Southeast Asia, Europe and South America.OSETMAC is able to do our own R&D, deliver production task on time and provide
customer service quickly. The manufacturing factories have already been granted ISO9001, and some of the main products have passed
CE certificate.
The goal of OSETMAC is to provide high-quality products to our customers, assist your business and become one of the leading
companies in woodwoking machines field.
