SYS-360 6 Function Automatic Edge Bander for Woodworking Power 7.4KW Weight 1200 kg
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Condition | New | Type | Edge Banding Machine |
|---|---|---|---|
| Voltage | 380v, 380v 50HZ 3 Ph | Dimension(L*W*H) | 4100x800x1560mm |
| Power (kW) | 7.4KW | Weight (KG) | 1200 Kg |
| Applicable Industries | Building Material Shops, Manufacturing Plant, Construction Works , Other | Warranty | 1 Year |
| Function | Gluing, Fine Trimming, Rough Trimming, End Trimming, Scraping, Buffing | Key Selling Points | Long Service Life |
| Panel Feed Speed(m/min) | 25m/min | Video Outgoing-inspection | Provided |
| Warranty Of Core Components | 1 Year | Core Components | Motor |
| Use | Plywood Production | Panel Thickness | 10-60mm |
| Panel Width | ≥60mm | Panel Length | ≥150mm |
| Workign Pressure | 0.6Mpa | Edge Thickness | 0.3-3mm |
| HS Code | 8465100000 | Gluing Pot Heating Power | 1.5KW |
| Conveyor Motor | 1.5kw | Port | Qingdao Port |
Product Description
Product Description
Automatic Edge Banding Machine SYS-360
Main Technical Parameter
SPECIFICATIONS | ||||
Model | SYS-360 | |||
Panel Thickness | 10-60mm | |||
Edge Band Thickness | 0.3-3mm | |||
Panel Width | ≥60mm | |||
Panel Length | ≥150mm | |||
Feeding Speed | 15m/min | |||
Working Pressure | 0.6Mpa | |||
Voltage | 380V/50HZ/3PH | |||
Gluing Motor | 0.37KW/50HZ/1400RPM | |||
End Cutting Motor | 0.37KW * 2/200HZ/12000RPM | |||
Rough Trimming Motor | 0.55KW * 2/200HZ/12000RPM | |||
Fine Trimming Motor | 0.55KW * 2/200HZ/12000RPM | |||
Buffing Motor | 0.37KW * 2/50HZ/1400RPM | |||
Conveyor Motor | 1.5KW | |||
Glue Pot Heating Power | 1.5KW | |||
Assistant Heating Power | 0.3KW | |||
Lighting Power | 0.05KW | |||
Total Power | 7.4KW | |||
Dimension | 4100x800x1560mm | |||
Wooden Case Package | 3900x870x1700mm | |||
Our Advantages
Features of SYS-360
Descriptions * 6 Functions: Gluing--End Cutting--Rough Trimming--Fine Trimming--Scraping--Buffing * Working Voltage: 380V/50HZ /3PH * PLC Touch Screen * CC highspeed motor. *Honeywell travel switch, contactor, air switch. *Air Tac solenoid valve, air cylinder,oil-water seperator. *14mm high strenth steel sheet for the whole machine. * In the machine is mounted lights. * Support customization for the machine appearance.
Packing&Shipping
After Sales Service
Our Service
The whole machine is guaranteed for one year, providing installation and use video, lifelong technical support and parts service
