High Precision Woodworking Edge Banding Machine Automatic Edge Bander

  • High Precision Woodworking Edge Banding Machine Automatic Edge Bander
  • High Precision Woodworking Edge Banding Machine Automatic Edge Bander
Place of Origin Qingdao, China
Brand Name OSETMAC
Certification CE,ISO
Model Number SYS-368
Minimum Order Quantity 1
Price Negotiable
Packaging Details Seaworthy wooden case
Delivery Time 15 days
Payment Terms T/T, L/C
Supply Ability 3000 sets per year

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Feature High Precision, High Efficiency. Application Edge Banding
Voltage 220V/380V/ Or Customized Function Glue,end Cutter, Trimmer, Scraping Buffing
Warranty 1 Year, 1 Year Usage Solid Wood, PVC, Melamine, And Veneer
High Light

woodworking edge bander

,

edge banding trimming machine
Leave a Message
Product Description

SYS-368 Automatic Edge Bander with Trimming for Panel Furniture and PVC





Product Description


1. Ideal for straight edge banding on solid wood, MDF, particle board, etc, edge banding tapes can be solid wood, PVC, melamine, and veneer.

2. Best quality and durable motor and electrical panels.

3. Funcions ,voltage and others can be customized.

4. High precision, high efficiency.





Applications:



This edge banding machine is suitable for PVC, ABS, MDF, Solid, shaving board, Melamine, Batten, Veneer ,plywood and particle board etc.





Specifications:



MODEL SYS-368
Panel Thickness 10-60mm
Edge Band Thickness 0.4-3mm
Panel Width ≥60mm
Panel Length ≥150mm
Feeding Speed 15-23m/min
Working Pressure 0.6Mpa
Voltage 380V/50HZ/3PH
Gluing Motor 0.75KW 50HZ 1400RPM
End Cutting Motor 0.37KW * 2 200HZ 12000RPM
Trimming Motor 0.75KW * 4 300HZ 18000RPM
Buffing Motor 0.37KW * 2 50HZ 1400RPM
Conveyor Motor 2.2KW
Lifting Motor 0.25KW
Glue Pot Heating Power 1.85KW
Assistant Heating Power 0.45KW
Lighting Power 0.08KW
Total Power 10.4KW
Dimension 4417x830x1610mm
Net Weight 1500KGS



Competitive Advantage:

  1. We can customize the outlook and functions of the machine according to your requirement.
  2. We have two wholly-owned manufacturing factories and can make sure of the delivery time.
